HUB With NVMe 9-IN-1 : M.2 NVMe SSD Enclosure With 9-IN-1 Docking Station,without the power adpter
2 Bay Dock and M.2 Hard Drive Enclosure
This ORICO dock is also a MVMe/NGFF 2 Bay hard drive enclosure.It fits for built-in M.2 M-KEY (NVME) protocol, the maximum 4T SSD, data transfer 30Gbps,and also support built-in M.2 B-KEY (SATA) protocol,the maximum 4T SSD, 6 Gbps data transfer; size is 22 × 80. Note: Dual bay does not support the use of hard drives with the same protocol.
9 in 1 M.2 Dual Bay Thunderbolt 3 Docking Station
Turn 1 USB-C port into 2x Thunderbolt 3 I/O 40 Gbps, 1x DP 1.4 8K@60HZ, 1x 10Gbps USB-A port, 1x 10Gbps USB-C port, 2x 5Gbps USB-A port and 1x Gigabit Ethernet, 1 3.5mm audio input and output, ORICOM.2 Thunderbolt 3 docking station with two slots can meet your various creative needs.
Ultra High Speed Transmission
This Thunderbolt 3 docking station can simultaneously control two 4K displays (one via DP, one via the Thunderbolt 3 interface) or an external 5K, 8K display and transfer high-speed data at up to 40 Gbit/s, use the flexible properties of the USB-C Thunderbolt 3 interface that can simultaneously output power/display/data.
Heat dissipation design and other functions
The Thunderbolt 3 docking station is made of all-metal material and is equipped with a fan to support heat dissipation. Avoid speed reduction, data loss etc. (Note: 1. SSD generates a lot of heat when working at high speed, can get very hot. Please touch gently. 2. As the docking station is equipped with a fan, the fan can make noise when it is running)
Main Features:
1. ORICO external drive docking station adopts USB 3.1 Gen 2 standard(USB C port), which supports an amazing data transmission rate up to 10Gbp(NVME),6Gbps,(NGFF)
2. Support Plug & Play and Hot-Swapping. Easy installation & no driver required.
3. Operating system compatibility: Windows, macOS, and Linux.
|
|
|
DC 24V 5A AdapterThe 120 W DC power adapter is exclusively designed to power the docking station in order to ensure all ports works properly. DO NOT use it to power any other devices. |
9 in 1 USB C docking stationTurn 1 USB-C port into 2x Thunderbolt 3 I/O 40 Gbps, 1x DP 1.4 8K@60HZ, 1x 10Gbps USB-A port, 1x 10Gbps USB-C port, 2x 5Gbps USB-A port and 1x Gigabit Ethernet, 1 3.5mm audio input and output. |
RJ45 LAN portFor stable and fast network connection, backward compatible with 10M/ 100M/ 1000Mbps. Internet connection automatically adjusts to the optimal level on Windows system. |
|
|
|
ORICO Dual-Bay NVME/NGFFThunderbolt 3 Docking Station |
Packing list1* M.2 PCIe Thunderbolt 3 Dock 1*Screw Driver 1*Thunderbolt data Cable 1*Power Supply 1* Heat Dissipation Pad |
|
If you want a longer Thunderbolt 4 cable(0.8m/2m), please click:
